本機是一款新型全自動高速敷料貼生產包裝設備，采用國內外先進技術，人機界面交互控制系統，全伺服驅動工位、電腦全程監測，可實現連續包裝生產。

The machine is a new type of high-speed wound dressing packaging production equipment,uses of advanced technology from abroad, Human-computer interface interactive control system. Full servo drive,in the operation, the computer system monitoring the whole production,continuous packaging production.

（1） 原料放卷采用恒張力系統控制，保證原材料卷徑發生變化時自動調節張力大小。

 Material unwinding is controlled by constant tension system, Make sure the tension is adjusted automatically when the coil diameter of raw material changes.

（2）設備基材自動糾偏控制，高速運轉中接料相位穩定，節約原材料。

Equipment raw material deviation correction control automatically.High speed operation, stable, save raw materials.

（3）各送料、切片工位采用歐姆龍、松下等知名伺服系統精 準定位控制，觸摸屏進行在線微調保證產品長度的穩定性。

Each feeding section and cutting section uses Adopt omron panasonic and other well-known servo system precise positioning control. Touch screen can be fine-tuned to ensure the stability of product length.

（4）包裝采用平壓封口方式，解決了滾壓設備封口不牢的弊端、封口拉力大小可根據包裝材料不同進行調節。包裝速度快、質量穩定，效率高、適用于淋膜紙、熱熔膠紙等材料的生產

The packaging adopts the method of flat sealing, which solves the disadvantage of weak sealing of rolling equipment, The sealing tension can be adjusted according to different packing materials. Fast packing, stable quality, high efficiency, suitable for the production of coated paper, hot melt adhesive paper and other materials.

（5）采用臺灣富臺光電進行色標跟蹤，切片大小穩定均勻

Taiwan KONTEC photoelectric is used to track the color code, and the slice size is stable and evenly.

（6）外包裝可在線進行生產日期噴碼

Date and batch number can be sprayed on the outer packing paper.

（7）設備具有產品產量計數以及成品輸計數數輸送功能。

The equipment has the function of counting the output of products and counting the delivery of finished products.

（8）安全性--設備工位異常報警以及斷料停機功能

Safety - abnormal alarm and stop function when raw materials used out.

（9）設備生產效率高，速度可達0-150片/分鐘

The production efficiency of the equipment is high, and the speed can reach 0-120 pieces/minute.

（10）設備配備記憶存儲功能，操作方便換料以及更換模具方便。保證產品生 產效率性和質量的穩定性。

The device is equipped with memory storage function, Easy to operate, change material and change mould.
